Mobile medical complex based on Gazelle CMF (Next, NN).

The mobile medical complex is made on the basis of the Gazelle all-metal van. Standard and extended Gazelle chassis of the Next and NN series are available as a car base.
The complex has an insulated van, made with a hinged or sliding side door. The inside of the van is lined with composite panels that are durable, absolutely corrosion and biological resistant, easy to clean and disinfect.

The equipment includes LED lighting, autonomous power supply, ventilation and heating systems, external side input. Additional options are possible under the order: installation of an autonomous air conditioner, a remote generator, video surveillance cameras, organization of hot water supply (a sink with an automatic water supply system). The medical vehicle can be equipped with a mobile medical and obstetric station, a diagnostic center, a vaccination station, a medical examination room, a cardiomobile, a medical laboratory, and much more.

The mobile medical complex is certified, has the approval of the Customs Union "On the safety of wheeled vehicles".
UNDERCARRIAGE AND BODY

  • Drive type - rear
  • Gearbox Gazelle Next / NN - 5MKPP / 6MKPP
  • Fuel consumption when driving at a speed of 60 km / h - from 8.5 l / 100 km
  • Fuel consumption when driving at a speed of 80 km / h - from 10.3 l / 100 km
  • Maximum vehicle speed 130 km/h
  • Wheel formula 4 x 2
  • Ground clearance 170 mm
  • Wheelbase standard/long chassis 3745/3950 mm
  • Dimensions standard/long chassis (LxWxH) 6232/6932 x 2068 x 2750 mm
  • Gross weight 3500 kg/ 4600 кг
MOTOR

  • Engine - Cummins 2.8, ISF2.8s5F148
  • Type - diesel turbocharged
  • Ecological class - Euro 5
  • Engine displacement 2.8 l
  • Engine power 139 l s
MOTOR

  • Van Gazelle Next / NN all-metal white
  • Color scheme in accordance with GOST 28385-89
  • Interior ceiling and wall cladding: aluminum-coated composite panels with high resistance to abrasion, acid environments, detergents and disinfectants
  • Thermal insulation of the ceiling, doors, walls of the van
  • Frosted external glazing
  • Doors: service sliding/swing door in the front, double-leaf swing door on the rear end with a latch in the open position (possibly without it)
  • Floor: transport plywood; waterproof, antistatic, non-slip polymer coating of autolines with waterproofing of all seams
  • Hatch ventilation
  • Partition with a sliding frosted window separating the driver's cab from the passenger compartment
  • Double passenger seat in the cab
OPTIONAL LIFE SUPPORT EQUIPMENT

  • Lighting: LED lamps in the salon, illumination of doorways
  • Van electrics: electrical network 220V, sockets 220V
  • External onboard input for 220V, external input cable with RCD for connection to an external power supply or generator
  • Filtering unit
  • Autonomous van heater

ADDITIONAL EQUIPMENT, FURNITURE, MEDICAL EQUIPMENT ACCORDING TO THE TECHNICAL REQUIREMENTS OF THE CUSTOMER
Delivery in Russia
Our company delivers our special vehicles across Russia in various ways
Warranty service
The chassis is covered by the manufacturer's warranty (24 months). The equipment van has a 12 month warranty.
