The food truck is made on the basis of a new generation Gazelle NN car in an all-metal body with an extra-long wheelbase. On request, a modification based on the chassis of the all-metal GAZelle-NEXT is also available.
The mobile cafe has an insulated all-metal van, suitable for year-round use in any climatic and geographical conditions.
For issuing orders on the left side of the car, a lifting board with a showcase was mounted. Entrance to the salon is carried out both through a sliding door in the front of the van, and through hinged doors in the rear overhang.
In the salon there is a full-fledged mobile kitchen, equipped with the necessary professional equipment: freezers, refrigerators, a frying surface, a sink with an autonomous water supply, an extractor hood, etc. The equipment can be changed for any food truck format: a mobile coffee shop, a burger shop, a pizzeria, a steak house, a pancake shop, a bakery, a shawarma shop, etc.
Uninterrupted operation of the kitchen unit is provided by autonomous life support systems: 220V power supply, LED lighting, ventilation and heater. For connection to an external power supply sockets of onboard input are provided. It is possible to install a generator and an independent air conditioner.
The food truck is certified, has the approval of the Customs Union "On the safety of wheeled vehicles".
UNDERCARRIAGE AND BODY
Drive type - rear
Gearbox Gazelle Next / NN - 5MKPP / 6MKPP
Fuel consumption when driving at a speed of 60 km / h - from 8.5 l / 100 km
Fuel consumption when driving at a speed of 80 km / h - from 10.3 l / 100 km
Maximum vehicle speed 130 km/h
Wheel formula 4 x 2
Ground clearance 170 mm
Chassis wheelbase 3950 mm
Chassis dimensions (LxWxH) 6932 x 2068 x 2750 mm
Full of masses 4600 кг
Engine - Cummins 2.8, ISF2.8s5F148
Type - diesel turbocharged
Ecological class - Euro 5
Engine displacement 2.8 l
Engine power 139 l s
Van Gazelle Next / NN all-metal painted in the color of the customer's choice
Internal lining of the ceiling and walls: composite panels with aluminum coating, stainless steel
Thermal insulation of the ceiling, doors, walls of the van
Exterior glazing of the salon
Doors: service sliding/swing door in the front, double-leaf swing door on the rear end with latch-open
Floor: transport plywood; waterproof, antistatic, non-slip polymer coating of autolines with waterproofing of all seams
Partition with a sliding frosted window separating the driver's cab from the passenger compartment
Double passenger seat in the cab
OPTIONAL LIFE SUPPORT EQUIPMENT
Lighting: LED lamps in the salon, illumination of doorways
Van electrics: electrical network 220V, sockets 220V
External onboard input for 220V, external input cable with RCD for connection to an external power supply or generator
Autonomous van heater
ADDITIONAL EQUIPMENT, FURNITURE, MEDICAL EQUIPMENT ACCORDING TO THE TECHNICAL REQUIREMENTS OF THE CUSTOMER
Delivery in Russia
Our company delivers our special vehicles across Russia in various ways
The chassis is covered by the manufacturer's warranty (24 months). The equipment van has a 12 month warranty.
